TrapMaster Pro

• TrapMaster Pro
• TrapMaster Case
• Shoulder strap
• Universal charger (EU, UK, AU, US)
• Charger for the car (cigarette socket)

Weight: 2 kg / 4.4 lb
Color: Moss green
Dimension: 22 x 13 x 29,6 cm / 8.67 x 5.12 x 11.66 in

Fast charging: 2,5 hours to 70%
Full charge: 5 hours to 100%
Capacity: 5200 mAh

Download the user manual for the TrapMaster Pro here.

Quick start guide for the TrapMaster Pro can be found here: Quick start

The TrapMaster Pro is our fastest thrower yet and can launch our Bio Clays Pro targets with up to 100 km/h.

Speed settings
Each time you increase the setting by 1, it increases the speed by ~5 km/h

• 0 = ~55 km/h
• 1 = ~60km/h
• 2 = ~65 km/h
• 3 = ~70 km/h
• 4 = ~75 km/h
• 5 = ~80 km/h
• 6 = ~85 km/h
• 7 = ~90 km/h
• 8 = ~95 km/h
• 9 = ~100 km/h

The TrapMaster Pro is to be used with our Bio Clays Pro targets.

Bio-Clays & Bio-Clays+ can also be launched with the TrapMaster Pro. But they can only be launched at a max speed setting of 0 (55 km/h), otherwise they will break during launch.

The TrapMaster Pro can launch up to 300 times on one full charge. Which means you can launch up to 600 clays if you only launch doubles/pairs.

Yes, It is possible to place the TrapMaster Pro on a camera tripod with a ¼ inch screw, (which is the most common screw on tripods).

An example of a tripod you can use, can be found here.

Important features required of the tripod:

• Screw type: ¼ inch screw
• Has to have a load capacity of at least 3 KG / 6.6 lb.

1. Take the charger from your case and plug it into a power outlet.
2. Connect the other end of the charger to your TrapMaster Pro.
3. Make sure the charging LED beneath the ON/OFF button lights up to ensure it's charging.
4. The battery will automatically stop charging when it reaches full capacity. (The charging LED will turn off once its fully charged.)
5. Unplug your TrapMaster Pro when it’s fully charged. You should never leave your TrapMaster Pro in the charger.

To check the TrapMaster Pro’s current battery level, do the following:

1. Turn the TrapMaster Pro on.
2. Wait 10 seconds.
3. Check the color of the indicator LED which is placed above the speed regulator.

The indicator LED can show two different colors.

• Green = 33-100%
• Red = 0-33%

• Always charge the TrapMaster Pro before use.
  In order to maintain and preserve the battery, the TrapMaster Pro automatically starts discharging the battery.
• To keep your battery in a healthy condition, you should charge it every 3 months.
  Otherwise it will worsen the battery’s life time drastically.
• Try to avoid letting your battery run empty.
  The best way to preserve the battery is to fully charge it before storing it. Especially if its for more than three months.
• The batteries will not charge below 5°C.
  If it’s cold outside, it’s always better to charge inside at room temperature (between 15-25Cº).
• Charge your TrapMaster Pro indoors in a well-ventilated dry location (moisture and extreme temperature fluctuations can affect the charging process).

Outside temperatures can significantly influence the performance of your battery. The power output of a battery will be better in mild to warm weather rather than in sub-zero conditions.

In low temperatures, you may notice that your battery drains faster and that the power output feels slighty less powerful.

We recommend starting the TrapMaster Pro on a lower speed for the first few minutes to give it a chance to warm up properly.

If your TrapMaster Pro is not working as intended, the first thing you should do is restart it.

Turn it OFF, wait 10-15 seconds then turn it ON again.

1. Turn it ON.
2. Do NOT attach a clay target.
3. Press the blue load button.
4. Point it towards the grass or away from any person, object or animal.
5. Press the red fire button.
6. Try the above 2-3 times.

If the above doesn’t solve your challenge, please contact us.
